Triumph 16,000 lb Two Post Overhead Car Lift | NTO-16
Need a Lift for Heavy-Duty Trucks? The Triumph NTO-16 Lift Handles 16,000 lbs with Certified Safety and Power
Finding a reliable 2 post car lift for heavy-duty vehicles can feel like searching for a needle in a haystack. Especially when you're dealing with inconsistent quality, unclear specs, and setups that don’t meet shop safety standards. Many auto shop owners struggle to find a lift that can handle larger trucks and commercial vehicles without sacrificing ease of use or long-term durability. Whether you're expanding your shop or upgrading your current lift, you need something that offers both strength and smart design. Above 14,000 lbs the certification requirements become non-negotiable. Lifts at this capacity that haven't been ISO and CE tested at full load aren't worth the structural risk, no matter the price.
That’s exactly where the Triumph NTO-16 Lift comes in. Built with a beefy 16,000 lb capacity, this lift is a true workhorse. It’s engineered for high-demand environments, from commercial garages to municipal service bays. And thanks to its overhead direct-drive design, you're getting clean floor access with maximum lifting efficiency. No chains, fewer moving parts, and less maintenance. Both ISO 9001 and CE certifications cover the structural design and the manufacturing process, with included truck adapters and mounting hardware giving you a complete out-of-the-box install package.
Certified to ISO 9001 and CE standards, this 2 post auto lift was made for professional use. It’s not just about lifting heavy vehicles. It’s about doing it safely, quickly, and without compromising on space. From the electrical safety shutoff to the single-point lock release, every detail was designed with shop efficiency in mind. Whether you're working on lifted trucks, box vans, or fleet vehicles, the NTO-16 delivers peace of mind. And serious power. For shops handling the heaviest commercial work, fleet trucks, work vans, light-commercial vehicles, the NTO-16 brings full certification and structural rating into a price band that independent shops can actually afford.
Want a better fit for your space? We offer Vehicle Lifts in various footprints and heights.
Benefits of the Triumph NTO-16 Vehicle Lift
Key Features of the Triumph NTO-16 16,000 lb Two-Post Overhead Car Lift You'll Love:
• 16,000 lb Lifting Capacity: Built to handle diesel trucks, fleet vehicles, and large SUVs with ease. Reinforced arms and structure provide heavy-duty performance for shops that need maximum versatility. 16K capacity covers crew cabs, dually pickups, work vans, and most commercial vehicles requiring 2-post service.
• Overhead Direct-Drive System: Utilizes direct-drive cylinders for smoother, more efficient lifting. No chains, no mess. The open overhead design eliminates obstructions and increases technician mobility between posts. Overhead direct-drive design is structurally simpler than older chain or cable systems and easier to maintain over years of cycling.
• Single-Point Lock Release: Control both safety locks from one side of the lift. Speeds up daily operations, reduces training time for new techs, and lowers the risk of operational errors in busy shop environments. Single-point release lets one operator manage the full lift cycle without coordinating with a helper.
• Electrical Override Safety Shutoff: Automatically stops the lift at maximum height to protect equipment and personnel. A critical safety feature for high-traffic bays, preventing over-extension during busy service hours. Electric override safety stops the lift before contact damage, even if operator attention slips during cycling.
• Free Mounting Hardware & Truck Adapters: Includes everything you need. No surprise costs. Truck adapters are ready to go for standard and lifted vehicles, reducing downtime and boosting shop efficiency. Mounting hardware and truck adapters ship standard, no add-on purchases needed at delivery.
• ISO 9001 and CE Certified: Manufactured under strict international quality standards, ensuring safe, compliant, and long-lasting operation in professional shop environments. ISO 9001 and CE certifications cover structural design and manufacturing process. Third-party validation commercial shops require.
Minimum Garage Requirements
✔ Ceiling Height: At least 171" (14'3") recommended ✔ Footprint: 102" drive-thru x 142" overall (8'6" x 11'10") ✔ Concrete Thickness: Minimum 6" (152.4 mm) ✔ Concrete Strength: Minimum 3,000 PSI compressive ✔ Electrical: 220 Volt ✔ Overall Lift Height: 165" (13'9") (measure before ordering)
✔ Ceiling Height: At least 171" (14'3") recommended
✔ Footprint: 102" drive-thru x 142" overall (8'6" x 11'10")
✔ Concrete Thickness: Minimum 6" (152.4 mm)
✔ Concrete Strength: Minimum 3,000 PSI compressive
✔ Electrical: 220 Volt
✔ Overall Lift Height: 165" (13'9") (measure before ordering)
*Concrete must meet the manufacturer's minimum requirements as specified above. Installing this lift on inadequate concrete may result in serious injury or death. It is the customer's responsibility to verify concrete thickness and strength prior to purchase and installation. Stacking taller vehicles vertically may require additional ceiling height. Measure your specific vehicles before ordering. Note: 2-post overhead lifts inherently require tall ceilings. Verify your overhead clearance before ordering.
Triumph NTO-16 Two-Post Auto Lift Specifications |
|
| Manufacturer | Triumph |
| Capacity | 16,000 lbs |
| Overall Height | 165" |
| Overall Width | 142" |
| Lifting Height | 72" |
| Distance Between Posts | 116" |
| Drive Thru Width | 102" |
| Lowered Height | 7" |
| Base Plate Size | 20" x 20" |
| Truck Adapters | Yes |
| Lock Release | Single Point |
| Electric Safety Cutoff | Yes |
| Lift Time | 40 Seconds |
| Voltage | 220 Volt |
| Horsepower | 3 HP |
| Concrete Requirements | 6" Slab, 3,000 PSI |
| Style | Overhead |
