Race Ramps Portable Pit Stop Ramps, 14 Inch Lift
Fourteen Inches of Lift That Packs Into a Trailer: Portable Pit Stop Ramps
A wrap shop needs the whole car in the air and every panel reachable. A race team needs the same thing in a paddock with no lift and no power. Both problems normally end at a permanent installation neither of them can travel with.
Portable Pit Stop Ramps are the answer to both. They raise a car 14" off the ground on a 10.4 degree approach, over a 220" run, and the whole thing is a multi piece design where no single piece weighs more than 40 lbs. It assembles by hand and packs down to travel.
Each ramp carries 1,500 lbs for 6,000 lbs of vehicle, takes tires up to 14" wide, and suits wheelbases from 90" to 115". The full set weighs 250 lbs, which sounds like a lot until you compare it to any lift that reaches the same height.
Sold as a pair, in standard or racer form. If you want a permanent installation instead, see our scissor lifts. Talk to a specialist about which makes sense for your shop.
Benefits of Portable Pit Stop Ramps
Standard or Racer
Both give the same 14 inches of lift on the same 10.4 degree approach with the same capacity. The difference is what is cut into the top deck.
• Standard, RR-PPS: A solid top deck. The right choice for wrap work, detailing and general service, where you want continuous support under the tire.
• Racer with Scale Cutouts, RR-PPS-R: Adds 15" cutouts sized to drop corner weight scales into the deck. The car sits on the scales at ramp height, so you can corner balance and set up the car without ever putting it on the floor.
If you do not own scales and do not intend to, take the standard. If you corner weight cars, the racer version saves buying a separate scale platform entirely.
| Portable Pit Stop Ramps Specifications | |
| Manufacturer | Race Ramps |
| Models | RR-PPS (standard) | RR-PPS-R (racer, 15" scale cutouts) |
| Sold As | Pair. Multi piece, no piece over 40 lbs |
| Lift Height | 14" |
| Approach Angle | 10.4 degrees |
| Dimensions | 220" L x 16" W x 14" H |
| Wheelbase Range | 90" to 115" |
| Capacity | 1,500 lbs per ramp | 6,000 lbs total |
| Maximum Tire Width | 14" |
| Weight | 250 lbs per set |
| Material | Expanded foam with traction coating |
| Colour | Black |
| Origin | Made in the USA |
| Warranty | 1-year manufacturer warranty | 30-day satisfaction guarantee |
Portable Pit Stop Frequently Asked Questions
Should I buy this or a lift?
A lift goes higher, lets you stand under the car, and costs less per inch of height. Buy the ramps instead if you need to move the setup, if you cannot anchor into the slab, if you are in a leased unit, or if you are wrapping and need the sills clear of lift arms. Buy a lift if it stays in one bay and you want to work standing up. Call us and we will tell you honestly which fits your situation.
What are the scale cutouts for?
Corner weighting. The racer version has 15 inch recesses in the deck sized to take corner weight scales, so the car sits on the scales at ramp height. You can set ride heights, adjust the corner balance, and read the numbers without lowering the car each time.
How much space does a set need?
Each side is 220 inches, so over eighteen feet, plus a straight approach. This is a workshop or trailer product rather than a single garage one. It breaks into pieces of 40 lbs or less for storage and transport.
Can one person set them up?
Possible but slow. No single piece is over 40 lbs so nothing is beyond one person, but with a 250 lb set across two sides it is a two person job if you want it done quickly and aligned properly.
Will my car fit?
Wheelbases from 90 to 115 inches and tires up to 14 inches wide, which covers most sports cars, muscle cars and supercars. Long wheelbase sedans and trucks fall outside the range. Check both figures against your car before ordering.
This is a big purchase. Talk to a Pitstop Pro specialist before you commit.
