Katool 4 Post Storage Lift - 9,500lb Capacity | KT-4H950
Tired of Install Guesswork? The Katool KT-4H950 9,500 lb 4-Post Lift Makes Parking and Service Simple
Shopping for a 4-post lift can feel like a guessing game -- capacity ratings, safety lock specs, slab requirements, and power options all blur together fast. If you're wondering whether the lift will actually be safe, fit your ceiling, and work with the power you already have, you're not the only one asking those questions. The KT-4H950 by Katool is built to remove that uncertainty with a real 9,500 lb capacity, four mechanical locks with primary and secondary catches, and a single-point manual safety release you control from one spot. It's CE certified at 115% dynamic and 150% static load testing -- the rated capacity isn't the ceiling, it's the floor.
What sets this lift apart from others in the 9,000-10,000 lb range is how much it gives you out of the box. Casters, aluminum ramps, a jack tray, and drip trays are all included -- no hunting for essentials after delivery. The power-side column installs on the left, right, front, or rear, so electrical routing fits your shop instead of the other way around. Adjustable safety lock ladders let you stop at the right working height, and the cable-and-pulley system keeps both platforms synchronized for level lifts every time. With 97-inch posts and 80.7 inches of underneath clearance, you get real headroom for storage or undercarriage work.
For home garages and light-duty shops, this lift doubles as a daily-use storage platform and a reliable service lift. Drive on, park underneath, and stop worrying about whether the equipment is up to the job. It's engineered for free-standing use with no anchor bolts required, runs on 110V or 220V, and lifts in about 90 seconds. If you need a 4-post lift that fits right, installs clean, and doesn't cut corners on safety or accessories -- this is the one that checks every box.
If this lift isn't the right fit, view the rest of our 4-post lift lineup or call us at (470) 208-2754.
Benefits of the Katool KT-4H950
Key Features of the Katool KT-4H950 4-Post Lift You'll Love:
• Four Mechanical Locking Devices: Each column houses primary and secondary mechanical locks that engage automatically as the platforms rise. You're not relying on hydraulic pressure alone -- your load is physically supported at the chosen height. This redundant design adds a crucial safety margin whether you're storing a vehicle or working underneath one.
• Adjustable Safety Lock Ladders: Dial in working height to match the job and your ceiling. Multiple lock positions make quick work of anything from under-car inspections to wheel and tire tasks with a rolling jack. Because locks engage into steel ladders, you get consistent, repeatable stops every time without any guesswork.
• Flexible Power-Side Column Placement: Install the power unit on the left, right, front, or rear to fit your workspace. This makes electrical routing simpler and keeps controls where they're most convenient. A cleaner install means fewer trip hazards, better shop flow, and less time spent on setup day.
• 97-Inch Posts with 80.7" Underneath Clearance: Taller posts give you real headroom for storage and service compared to shorter 4-post models. You get 80.7 inches of usable clearance under the runways when fully raised -- enough to park a sedan or SUV underneath while the top vehicle stays stored. Measure your ceiling once and know it fits.
• Everything Included Out of the Box: Ships with casters for repositioning, aluminum drive-on ramps, a jack tray for bottle jacks, and drip trays to keep your floor clean. Most competitors charge extra for at least half of this or don't offer it at all. You unbox it, set it up, and start working -- nothing else to buy.
• Free-Standing Design: Engineered for free-standing use without bolting to the floor, which means simpler installation and no drilling into your slab. Set it up, drive on, and start working -- no anchor bolts required for normal operation. Ideal for renters, seasonal garages, or anyone who might relocate the lift down the road.
Minimum Garage Requirements
✔ Ceiling Height: At least 102" (8'6") recommended ✔ Floor Space: 215" L x 113" W (17'11" x 9'5") ✔ Concrete Thickness: Minimum 4" (100 mm)
✔ Concrete Strength: Minimum 3,000 PSI, level, no cracks ✔ Electrical: 110V or 220V, 30A breaker, 10-gauge wire ✔ Post Height: 97" (8'1") -- measure before ordering
✔ Ceiling Height: At least 102" (8'6") recommended
✔ Floor Space: 215" L x 113" W (17'11" x 9'5")
✔ Concrete Thickness: Minimum 4" (100 mm)
✔ Concrete Strength: Minimum 3,000 PSI, level, no cracks
✔ Electrical: 110V or 220V, 30A breaker, 10-gauge wire
✔ Post Height: 97" (8'1") -- measure before ordering
*This lift is designed for free-standing use and does not require bolting to the ground for normal operation. Regardless of whether the lift is anchored, it must be installed on a concrete surface that meets the manufacturer's minimum requirements of at least 3.93" (100 mm) thickness and 3,000 PSI compressive strength. Installing this lift on inadequate concrete may result in serious injury or death. It is the customer's responsibility to verify concrete thickness and strength prior to purchase and installation.
| Katool KT-4H950 9,500 lb 4-Post Storage Lift Specifications | |
| Manufacturer | Katool |
| Lifting Capacity | 9,500 lb (4.3T) |
| Max. Lifting Height | 81" (2,146 mm) |
| Max. Underneath Clearance | 76.5" (1943 mm) |
| Lifting Time | 90 seconds up / ~40 seconds down |
| Height of Posts | 97" (2,464 mm) |
| Width Overall | 112.7" (2,863.5 mm) |
| Width Between Columns | 99.40" (2,525 mm) |
| Runway Length | 173" (4,394 mm) |
| Width Between Runways (Inside) | 37" (940 mm) |
| Width Outside Runways | 79.8" (1,880 mm) |
| Overall Length (without ramps) | 189.3" (4,805 mm) |
| Overall Length (with ramps) | 214.96" (5,460 mm) |
| Drive-On Ramp Length | 30.3" (770 mm) |
| Platform Surface | Diamond-plate, non-skid |
| Safety System | Four mechanical locks + adjustable safety ladders |
| Lock Release | Single-point manual release (operator side) |
| Synchronization | Steel cables & pulleys for level lifting |
| Included Accessories | Casters, aluminum ramps, jack tray, drip trays (all included free) |
| Optional Accessories | Sliding jack (pneumatic), extra jack trays |
| Motor | 110V/60Hz/3HP or 220V/60Hz/3HP (2.2 kW minimum) |
| Electrical Requirements | Dedicated circuit, 10-gauge wire, 30-amp breaker |
| Concrete Requirement | 4" (100 mm) @ 3,000 PSI, level, no cracks |
| Shipping Dimensions | 186" L x 30" W x 23" H -- 2,095 lbs |
| Warranty | 1 Year limited parts & defects | 3 Year structural |
